Hella Rotating Beacon 1609

Mounting Type

Flexible pipe sockets

Light Design

LED

Lamp Type

LED

Rated Voltage [V]

12

Rated Voltage [V]

24

Height [mm]

250

Outer diameter 1 [mm]

165

Light Function

with rotating warning signal

Light Colour

Yellow

Number of LEDs

8

Protection Type (IP Code)

IPX9K

Protection Type (IP Code)

IP5K4K

Registration Type

ADR/ GGVS Checked

Test Mark

ECE-R10

Test Mark

ECE-R65

Test Mark

RCM

Test Mark

SAE

Supplementary Article/Info 2

Electromagnetic Compatability (EMC)

Lens Colour

Yellow

Housing Colour

Yellow

Rotating beacon RPM [1/min]

123

Power Consumption [W]

10

Housing material

Plastic

Operating temperature from [ ?C]

-40

Operating temperature to [C? ]

60

Weight [g]
